Martindale EZ2500 Non Trip Earth Loop Tester

The Martindale EZ2500 non-trip earth loop impedance tester provides safe, switch-free operation for domestic, commercial and industrial applications.

The simple auto test sequence makes it ideal for where confirmation of safe earth loop impedance values are needed prior to installation of equipment and maintenance.

The auto test sequence means there is no need to worry about selecting the right type of loop test to avoid RCD tripping, it’s all done for you.

Martindale EZ2500 User Manual

Categories: Martindale Electric, Test Equipment For Electricians Tags: Ground/Earth Testers, Loop Tester

Description

The Martindale EZ2500 Non Trip Earth Loop Tester performs non-trip P-E and P-N loop impedance tests, PFC and PSC checks and lists all of the results on the clear backlit LCD display. A voltage check and confirmation of correct wiring is also performed.

The Martindale EZ2500 Non Trip Earth Loop Tester is supplied with a 10A Australian plug mains lead for testing for testing GPO outlets but an additional 3 wire test lead can be purchased (Martindale TL88) for testing at light fittings and fused connection units.

A soft carry case (TC210) and comprehensive manual are also included.

Martindale EZ2500 Non Trip Earth Loop Tester Features:

Non-trip and high current loop test
PFC & PSC test
Voltage and full socket wiring test
Smart and easy automatic testing
No batteries, ranges or switches
All results displayed together
HSE ‘professional socket tester

Martindale EZ2500 Specifications:

Nominal voltage rating	220-240V AC
Voltage range for wiring error detection	30-275V
Open loop indication	If open PE or PN Loop is detected, no Impedance Measurement takes place
Measurement range for impedance	198-264V, 50Hz
PE loop impedance ranges	0-8.99Ω, 9.0-89.9Ω, 90-899Ω, 900-1699Ω, 1700-3000Ω
PE loop impedance accuracy	0-8.99Ω ± 4% ± 0.05Ω9.0-89.9Ω ± 5% ± 0.5Ω90-899Ω ± 5% ± 5Ω900-1699Ω ± 5% ± 30Ω1700-3000Ω indicative
PFC & PSC test
PN loop impedance ranges	0-8.99Ω, 9.0-89.9Ω, 90-899Ω, 900-1699Ω, 1700-3000Ω
PN loop impedance accuracy	0-8.99Ω ± 4% ± 0.05Ω9.0-89.9Ω ± 5% ± 0.5Ω90-899Ω, ± 5% ± 5Ω900-1699Ω ± 5% ± 30Ω1700-3000Ω indicative
Frequency accuracy	± 4 %
Voltage accuracy	± 4%
Temperature range	-10° to 40° C at max 80 % Relative Humidity (Non-Condensing)
Supply	from mains
Power consumption	<1.6W
Pollution degree	2
Complies with	BS EN 61010-1, BS EN 61557 & BS 7671
Weight	240g approx.
Dimensions	145 x 85 x 53mm
Includes	TC210 carry case, mains lead and manual
*Note	Measurement accuracy can be affected by noise and highly inductive or capacitive components distributed on the supply
