The Kyoritsu 4140 LOOP/PFC/PSC Tester comes complete with everything you need for Loop, PFC, PSC and Phase rotation testing on an electrical installation according to the IEC 60364-6 (or its national equivalent standard).
The Kyoritsu 4140 measures prospective short current (PSC) and prospective fault current (PFC), phase rotation testing and both voltage and frequency. Designed to comply with an IP54 rating, the 4140 features anti-trip technology for trip free loop testing on RCDs rated to 30mA or above.
The Kyoritsu 4140 can test loop impedance up to 2000Ω via it’s 15mA AC test current. The prospesctive short current (PSC) and prospective fault current (PFC) can be read and the featured anti-trip technology allows trip free loop testing on all RCDs rated to 30mA or above. The dual digital display allows simultaneous measurements to be presented such as the loop and PFC/PSC.
The Kyoritsu 4140 provides the capabilities for “hands-free” testing with the lock-down test button with auto-start operation. As well as loop testing, the 4140 can perform phase rotation testing and both voltage and frequency measurements. The display and front panel keypad are backlit, providing operation in low light conditions.
Designed to an IP54 rating, the Kyoritsu 4140 is both waterproof and dustproof. The instrument is supplied with test leads, soft case, batteries and a shoulder strap.
With the Kyoritsu 4140 LOOP/PFC/PSC Tester a full set of new safety test leads is included, they have an overmould for maximum grip and are extremely robust.
The instrument also comes in a soft carry case, a quick reference guide locates on the instrument body, a strap belt and it is supplied with a calibration certificate.
Kyoritsu 4140 LOOP/PFC/PSC Tester Specifications:
Loop Impedance
| Function | L-PE ATT OFF | L-PE ATT ON | L-N / L-L |
|---|---|---|---|
| Rated Voltage | 230V (50/60Hz) | L-N: 230V (50/60Hz) L-L: 400V (50/60Hz) | |
| Operating Voltage | 100 – 280V (45 – 65Hz) | 100 – 500V (45 – 65Hz) | |
| Range (Auto-Ranging) | 20/200/2000Ω | 20/200/2000Ω (L-N<20Ω) | 20Ω |
| Nominal Test Current at 0Ω External Loop: Magnitude/Duration at 230V | 20Ω: 6A/40ms 200Ω: 2A/20ms 2000Ω: 15mA/500ms | L-N: 6A/60ms N-PE: 10mA/approx.5s | 20Ω: 6A/20ms |
| Accuracy | ±3%rdg±4dgt (*1) | ±3%rdg±6dgt (*1) | L-N: ±3%rdg±4dgt L-L: ±3%rdg±8dgt |
PFC (L-PE) / PSC (L-N / L-L) (*2)
| Function | PFC | PFC (ATT) | PSC |
|---|---|---|---|
| Rated Voltage | 230V (50/60Hz) | L-N: 230V (50/60Hz) L-L: 400V (50/60Hz) | |
| Operating Voltage | 100 – 280V (45 – 65Hz) | 100 – 500V (45 – 65Hz) | |
| Range (Auto-Ranging) | 2000A/20kA | 2000A/20kA (L-N<20Ω) | 2000A/20kA |
| Nominal Test Current at 0Ω External Loop: Magnitude/Duration at 230V | 20Ω: 6A/40ms 200Ω: 2A/20ms 2000Ω: 15mA/500ms | L-N: 6A/60ms N-PE: 10mA/approx.5s | 20Ω: 6A/20ms |
Phase Rotation
| Operating Voltage | 50 – 500V, 45 – 65Hz |
|---|---|
| Remarks | Correct phase sequence: displayed “1.2.3” and  markReversed phase sequence: displayed “3.2.1” and mark |
Volts
| Function | Volts | Frequency |
|---|---|---|
| Measuring range | 0 – 500V | 45 – 65Hz |
| Accuracy | ±2%rdg±4dgt | ±0.5%rdg±2dgt |
| Applicable standards | IEC 61010-1 CAT III 300V (500V L to L), IEC 61010-031, IEC 61557-1, 3, 7, 10, IEC 60529 (IP54), IEC 61326 (EMC) |
|---|---|
| Power source | 1.5V AA batteries × 6 *Use of alkaline batteries (LR6) is recommended. |
| Dimensions | 84 (L) × 184 (W) × 133 (D) mm |
| Weight | 860g (including batteries) |
| Included Accessories | Main cord (*3) Distribution board test lead (*4) 9155 (Shoulder strap) 9156 (Soft case) LR6 (Battery) × 6, Instruction manual |
(*1): Accuracy of L-N LOOP displayed on the Sub Display is synchronized with the one at L-N/L-L function.
(*2): PSC/PFC Accuracy is derived from measured loop impedance specification and measured voltage specification.
(*3): 7187A (Power cord [UK]), 7218A (Power cord [EU]), 7221A (Power cord [SA]), 7222A (Power cord [AU])
(*4): 7246 (Blue, Green, Red), 7247 (Black, Green, Red)
