FLIR DM284 Thermal Imaging Multimeter

The Flir DM284 is an all-in-one “Full Function” TRMS Digital Multimeter and Thermal Imager that can pinpoint where an electrical problem is to speed up the troubleshooting process. With a 160 x 120 FLIR Thermal Imager and the Infrared Guided Measurement (IGM™) technology, the DM284 enables you to scan panels, connectors, and wires from a safe distance and verify your findings with advanced contact measurement features to help solve the most complex electrical issues. Similar to the Fluke 279FC that has a 80×60 thermal image.

The Flir DM284 is able to point to the exact location of electrical problems through hotspots during the troubleshooting process. Instead of connecting to each individual component, users can easily use the thermal imager to scan all components and observe where the problem lies. Saving a substantial amount of time and resources. After finding the location of the issue with the thermal imager, use the DM284’s Multimeter functions to confirm your findings and obtain exact measurements.

The Flir DM284 has a Cat IV-600V & Cat III-1000V Safety Rating.

Authorised Australian Distributor

warranty-10-years

Flir DM284 Datasheet

SKU: Flir DM284 Categories: FLIR, Multimeters, Thermal Imagers / Infrared Cameras Tags: Multimeters, Thermal Imagers

The FLIR DM284 Advantage:

Pinpoint problems quickly and safely with IGM
Find more work by visually identifying electrical issues

See exactly where to measure with the 160 x 120 resolution FLIR thermal imager
All-in-one tool – carry just one device and always have access to thermal imaging
Scan a panel or cabinet for hazards using IGM without direct contact

Troubleshoot challenging problems with ease
Verify electrical issues with trusted readings every time, even with complex measurements

18-function DMM including VFD mode, True RMS, LoZ, and NCV
Thermocouple input
View thermal and electrical thermocouple measurements simultaneously

Design and functionality vital to professionals
An all-in-one tool that’s built to last

Built-in worklights and a laser pointer help you access difficult locations with lighting issues and pinpoint the location of the problem in the thermal image
Simple user interface and various thermal color palettes to choose from: Iron, Rainbow, Greyscale
Durable and drop tested with 10-year warranty

Flir DM284 Standard Accessories

dm284_acc

FLIR DM284 Specifications

Image Resolution	19,200 pixels (160 x 120)
Sensitivity	≤ 150 mK
Emissivity	4 Presets with Custom Adjustment
Accuracy	3°C or 3.5%
Range	14°F to 302°F (-10°C to 150°C)
FOV	46° x 35°
Laser Pointer	Yes
Focus	Fixed
Palette	Iron, Rainbow, Greyscale
Level & Span	Auto
AC / DC Volts Range	1000V
AC / DC Volts Accuracy	1% / 0.09%
AC / DC mVolt Range	600.0mV
AC / DC mVolt Accuracy	1% / 0.5%
AC / DC Amps Range	10.00A
AC / DC Amps Accuracy	±1.5%
Resistance Range	50 MΩ
Resistance Accuracy	0.90%
Flex Clamp Range	3000A AC (Optional TA72/74)
Flex Clamp Accuracy	± 3.0% + 5 digits
Frequency Range	99.99kHz
Frequency Accuracy	0.10%
Thermocouple Range	Type K -40°F to 752°F (-40°C to 400°C)
Thermocouple Accuracy	±1.0% + 5.4°F (DMM) ±1.0% + 9°F (IGM)
