The NEW Reed R8080 digital sound level meters (datalogger) are designed for sound level testing in numerous applications from 30 to 130 db. The gauges feature a sampling rate of 0.5 sec (digital) and 50 mS (analog), producing accurate results under a wide range of test conditions. A large backlit graphic LCD displays large characters and an analog digital bargraph. The R8080’s interface is very simple to use: just push a button and the meter will switch to the desired function quickly. USB output is provided for data collection purposes.
REED R8080 Features:
- Meets IEC651 Type II class requirements
- Records up to 64,000 datapoints (1MB)
- 60dB dynamic space in each range
- Real time clock and calander
- Fast/Slow time weighting
- “A & C” frequency weighting
- Min/Max function
- USB Interface
- Low level battery indicator
- Analog digital bargraph
- Backlit LCD display
- Tripod mount design for longterm monitoring
- Includes windscreen, USB cable, Windows
software, batteries and hard carrying case
Ideal Applications for the REED R8080
- Preventative Maintenance
- Industrial Machinery/Equipment
- Construction Sites
- Ensuring Safe Working Conditions
- Public Venues / Concerts
- Code Enforcement
- Traffic
- Appliance Noise Testing
- Long-term Measurement
- Recording of Acoustic Levels for Environmental Impact Studies
REED R8080 Specifications
Measuring Ranges | 30-130 dB Low: 30-90dB Med: 50 -110 dB High: 70 -130 dB Full: 30-130 dB |
Dynamic Range | 60 dB (in each range) |
Accuracy | ±1.4 dB |
Resolution | Digital: 0.1 dB Analog: 2dB |
Response Time | Digital: 500ms Analog: 50ms |
Frequency Range | 20 Hz to 8 kHz |
Frequency Weighting | A, C |
Time Weighting | Fast/Slow (125ms and 1s) |
Microphone | 0.5″ (12.7mm) electret condenser |
Digital Analog Bargraph | Yes (30 segment) |
Display | 4-digit LCD |
Backlit Display | Yes |
Min | Yes |
Max | Yes |
Alarm Indicators | Under and Over (visual on-screen) |
Datalogging Capabilities | Yes |
Real-Time Clock and Date Stamp | Yes |
Selectable Sampling Rate | Yes (between 1s and 60s) |
Internal Memory | 1mb (64,000 datapoints) |
Auto Shut-off | Yes (after 30 mins/off) |
Tripod Mountable | Yes |
Low Battery Indicator | Yes |
Power Supply | 4 x AAA batteries |
Output | Yes (AC/DC) |
Battery Life | Approx 50 hours |
PC Connectivity | USB |
Software OS Compatibility | Windows XP / Vista / 7 / 8 / 10 |
Product Certifications | CE, IEC 61672-1 Class 2, ANSI S1.4 Type 2 |
Operating Temperature | 32 to 104°F (0 to 40°C) |
Storage Temperature | 14 to 140°F (-10 to 60°C) |
Operating Humidity Range | 10-90% |
Dimensions | 10.4 x 2.5 x 1″ (264 x 63 x 29mm) |
Weight | 8.8oz (245g) |
