Megger EVCC300 |- Comprehensive Electric Vehicle Charger Checker with Essential Safety and Operational Checks

Discover the pinnacle of EV charger safety and performance checks with the Megger EVCC300 Charger Checker. Specifically designed for Electric Vehicle chargers, this all-encompassing tool performs essential safety and operational checks on mode 2 and single-phase mode 3 chargers with SAE J1772 Type 1 and Type 2 connectors. With the ability to conduct four key safety checks and four operational checks, the EVCC300 provides unmatched assurance of your charger’s functionality and safety. Nuisance tripping will no longer disrupt your EV charging experience. Bring precision, reliability, and peace of mind to your EV charging routine with the Megger EVCC300 Charger Checker.

Megger EVCC300 EV Charger Tester Datasheet

Click here to Make an Enquiry / Demo / Calibration

If you would like more information regarding this product, simply email us here.

SKU: MEGGER DLRO10HD-1-1-1 Categories: EV Charger Test, Megger, Test Equipment For Solar PV Tags: BITE5, MEGGER

Megger EVCC300 – EV Charger Checker

Revolutionize your maintenance, repair, and manufacturing check routines with the all-new Megger EVCC300 Charger Checker. Designed specifically for Electric Vehicle chargers, this advanced tool offers a streamlined and user-friendly solution for checking the safety and operation of mode 2 and single-phase mode 3 chargers.

Key for those seeking to perform fault-checks post-manufacture, post-repair, or as part of a regular maintenance schedule, the EVCC300 brings convenience and reliability to your fingertips.

Unmatched Features for Comprehensive Checks

The EVCC300 delivers on four pivotal safety checks, ensuring a hazard-free charging experience. These include a PE touch pad for grounding and voltage checks, a PE resistance test for exposed metal work grounding, an essential touch voltage test, and an RCD/GFCI protection check that validates the device tripping speed.

Moreover, our unique product helps to identify potential nuisance charger supply tripping which could disrupt your EV charging experience.

Delivering Operational Excellence

The EVCC300 stands apart with its four key EV charger operation checks. These include proximity detection operation check, control pilot operation check conforming to IEC61851-1 requirements, control pilot signal check, and EV charger output check.

Key Features At-a-Glance

Compatible with mode 2 and single-phase mode 3 chargers
Compatible with SAE J1772 Type 1 and Type 2 connectors
Effective in performing four essential EV charger safety checks
Ensures four crucial EV charger operation checks
Assists in identifying if nuisance tripping or RCD/GFCI is likely to occur
Reads control pilot state response from EV Charger to IEC61852-1 standards

Invest in the Megger EVCC300 Charger Checker for a seamless, safe, and efficient EV charging experience. Elevate your EV charger maintenance and safety checks to the next level today!

SPECIFICATIONS

SPECIFICATIONS

EVSE STANDARD IEC 61851-1:2017

EVSE SUPPLY OPTIONS (set in settings)

230 V single phase (EU / UK)
120 V single phase (US)
208 V / 240 V two phase (US)

SUPPLY MEASUREMENT

Voltage range: 5 V to 300 V

Voltage resolution: 1 V

Voltage accuracy: ± 5%, ± 2 digits

Voltage measurement: L to N, L to PE and N to PE

Reverse polarity indication: L to N, for single phase option only

Frequency range 45 Hz to 65 Hz

Frequency resolution: 1 Hz Frequency accuracy ± 1 digit

EVSE INTERFACE (EV charger function) tests:

1. Proximity detection (PP) states

Read only

2. Control pilot (CP)

No proximity

Proximity detected, unlatched Proximity detected, latched

Set and read states: State A – Disconnected

State B – Connected State C – Charging

State D – Charging without ventilation

State E – CP short to PE

Read only state State F – EVSE charger fault condition

Maximum voltage ± 14 V

Frequency range 940 Hz to 1040 Hz

Duty cycle range 8% to 97%

Maximum charging current indication according to IEC 61851-1:2017, tables A.7 and A.8

RESISTANCE OF EARTH PROTECTIVE CONDUCTOR (RPE)

Test current: 200 mA

Resistance range: 0 to 10 Ω Resistance resolution: 0.01 Ω Resistance accuracy: ± 5%, ± 2 digits

RCD/GFCI TESTS:

Trip time accuracy: ± 1%, ± 1 ms

Trip current accuracy: ± 3% (apply to all RCD/GFCI tests)

PERSONAL PROTECTION TESTS, 230 V SINGLE PHASE:

RCD 30 mA AC TEST

Test current: 31.5 mA AC

(5% above nominal trip current) Test current accuracy: ±1.0 mA

Max. test time: 300 ms

Polarity selection: 0° and 180° of an input sine wave

RCD 6 mA DC TEST

Test current ramp up at rate of 6 mA in 2.5 s,

then held at 6 mA DC Test current accuracy: ±0.5 mA

Ramp polarity: positive and negative ramp

Max. test time: 12.5 s

Polarity selection: 0° and 180° of an input sine wave

PERSONAL PROTECTION TESTS, 120 V SINGLE PHASE / 240 V TWO PHASE

GFCI/CCID 5 mA AC test

Test current: 6 mA AC Test current accuracy: ±0.5 mA Max. test time: 5.59 s

Polarity selection: 0° and 180° of an input sine wave

GFCI/CCID 20 mA AC test

Test current: 21 mA AC

(5% above nominal trip current) Test current accuracy: ±0.5 mA

Max. test time: 5.59 s

Polarity selection: 0° and 180° of an input sine wave

NUISANCE TRIPPING TESTS, 230 V SINGLE PHASE

RCD AC ramp test

Test current AC current ramp up to 30 mA in 2 mA steps

Test current accuracy: ±0.5 mA Step time: 300 ms

Max. test time: 4.5 s

RCD DC ramp test

Test current ramp up at rate of 6 mA in 2.5 s,

then held at 3 mA DC.

Max. test time: 11.25 s

NUISANCE TRIPPING TESTS, 120 V SINGLE PHASE / 240 V TWO PHASE

GFCI/CCID 5 mA AC test

Test current AC current ramp up to 6 mA in 0.5 mA steps

Test current accuracy: ±0.5 mA Step time: 100 ms

Max. test time: 1.2 s

GFCI/CCID 20 mA AC test

Test current AC current ramp up to 20 mA in 1 mA steps

Test current accuracy: ±0.5 mA Step time: 100 ms

Max. test time: 2 s

TOUCH VOLTAGE TEST

Options: 25 V or 50 V limit

Test current typically 1/3 of RCD nominal test current

TOUCH CONTACT PAD TEST

Dangerous voltage indication at PE conductor

POWER SUPPLY

Battery: Four AA cells

CONNECTIONS

Type 2 male – main test connection

4 mm shrouded socket on base of handle – RPE test return connection

LANGUAGES

User Interface: English, French, German and Spanish

User guide: English, French, German and Spanish

DIMENSIONS AND WEIGHTS

Dimensions are (L x H x W)

24 x 18 x 8.6 cm.

Weight (without batteries)

583 g

SAFETY

Standards IEC 61010-1:2010

Safety category CAT II 300 V

ENVIRONMENT

Operational temperature: 0 ºC to 40 ºC Storage temperature -10 ºC to 70 ºC

Operating humidity 90% R.H. at +40 °C max Maximum altitude: 2000 m

Dust and moisture ingress: IP40 to IEC60529 in use

APPLICATION

Safety and operation checks on mode 2 and single phase mode 3 charge points (level 1 and two phase level 2 in the USA)
Connects to SAE J1772 Type 1 and Type 2 charger connectors only
Checking charger following installation before hand over to customer. This cannot be used for Installation Certification without the use of the EVCA210 and MFT1741+
Checking charger as part of a regular maintenance schedule
Checking charger following repair before hand over to customer
Checking chargers following manufacturing as part of a QA inspection
Fault checking when customer reports charger issues to car dealership/service centre
